Architectural Flood Light ZTGL-1401

Characteristics

General Information

Compliance

FCC

RoHS

CE

Electrical Information

Electrical Class

Class I US

Class I EU

Class III US

Class III EU

Nominal Voltage

DC24V

120V 50-60Hz

120-277V 50-60Hz

220-240V 50-60Hz

Surge protection (kV)

10

Control protocol(s)

0-10V

Optical Information

LED Color temperature(K)

1800-6500

RGBW

Color redering index (CRI)

70

Performance

Luminaire output flux (lm)

1200-12000

Power consumption (W)

24-150

Luminaire efficacy - up to (lm/W)

100

Housing and finish

Housing

Die-cast aluminum

Optic

PC

Protector

Glass cover

Tightness level

IP65

Key Features

Construction

  • Rugged die-cast aluminum housing and pc lens.
  • Housing has direct contact with the driver to help maintain low temperature and long lifespan.
  • Housing is completely sealed against moisture and  environmental contaminants.

Electrical

  • Impact and UV-resistant polycarbonate lens is precisely designed to give a specific light distribution, maximizing efficiency and application spacing.

Controls

  • Optional 10KV SPD.
  • Optional button photocell.
  • Optional motion sensor.
  • Control:DMX512/RDM(wireless/DALI/0-10V available on request).
  • DMX channel:FW(1ch),TW(2chs),RGBW(4chs).

Installation

  • 1/2 In Threaded knuckle mount, Yoke.

5-year limited warranty

  • Estimated 50,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations.

Listings

  • IP65(UL listed for wet locations).
  • Rated for ambient operating temperature -40°F to 108°F (-40°C to 40°C).

Dimension

This product is available in 6 sizes to meet different application scenarios.

Download

Data Sheet-US

ZTGL-1401-US
Download

Data Sheet-EU

ZTGL-1401-EU
Download

Explore Dalite Lighting Products

Our Most Frequently Asked Questions

The following is a discussion about the key issues of our products.

What about the lead time?

We offer 3-month delivery for project-based services and 45-day delivery for non-project services. We can also accommodate special deadline requests.

Do you have any MOQ limit for led street light orders?

Low MOQ, 1pc for sample checking, is available.

How do you ship the goods, and how long does it take to arrive?

We usually ship by DHL, UPS, FedEx, or TNT. It usually takes 3-5 days for delivery. Airline or sea shipping is also optional.

Is it OK to print my logo on the led street light product?

Yes. Please inform us formally before our production and confirm the design first besides our sample.

Do you offer a guarantee for the products?

Yes, we offer a 2-5 years warranty on our products.

How to deal with the faulty?

Firstly, Our products are produced in a strict quality control system, and the defective rate will be less than 0.2%. Secondly, during the guarantee period, we will send new lights with new orders for small quantities.
